Plan Overview
Balanced Proportions For Everyday Guest Living
The source drawing documents a 25-by-20-foot enclosed footprint totaling 500 square feet.
One bedroom, one bathroom, a closet, and an open living and kitchen zone organize the compact plan.
Simple Rectangle
The 25-by-20-foot footprint supports an efficient, straightforward building form.
Private Suite
The bedroom, bath, and closet are separated from the main living zone.
Interior & Exterior Renderings
500 Sq Ft 25' x 20' One-Bedroom Casita Floor Plan Renderings
Selected exterior and interior renderings show the building form, arrival, and distinct living spaces without repeating room angles.
Floor Plan
Clean Layout Reference
The authoritative source documents a 25-by-20-foot rectangle with one bedroom, one bath, closet storage, and open living space.
Build Quality
Designed For Arizona
Use this cutaway as a visual guide to spatial relationships and building form. Final structure, systems, assemblies, and code details are developed during project-specific design and engineering.
