Plan Overview
A Broad Footprint With A Spacious Living Core
The source drawing documents a 34-by-22-foot overall footprint for the 748-square-foot plan.
Printed room areas include 415 square feet of living space, a 204-square-foot bedroom, 108-square-foot bath, and 16-square-foot closet.
Large Living Zone
The open living area is labeled at 415 square feet and includes the kitchen program.
Private Bedroom
The bedroom is labeled at 204 square feet with a separate 16-square-foot closet.
Interior & Exterior Renderings
748 Sq Ft 34' x 22' One-Bedroom Casita Floor Plan Renderings
Selected exterior and interior renderings show the building form, arrival, and distinct living spaces without repeating room angles.
Floor Plan
Clean Layout Reference
The authoritative source shows a 34-by-22-foot footprint with a large left-side living and kitchen zone and bedroom, bath, and closet to the right.
Build Quality
Designed For Arizona
Use this cutaway as a visual guide to spatial relationships and building form. Final structure, systems, assemblies, and code details are developed during project-specific design and engineering.
